Bacharach HI FLOW Sampler User Manual

Hi Flow Sampler Operation
Instruction 0055-9017
25
3.16 Importing Saved Data into a Spreadsheet
Test records that were downloaded to a personal computer per Section
3.15.1 can be imported into spreadsheet programs that are capable of
importing comma-delimited files. Note that each data record consists of
24 fields, some of which may be blank because of options not being
installed.
TABLE 3-1. COMMA-DELIMITED FIELDS
Field
Label in Column
Heading
Description
1 Record# Test Record Number
2 Inst.Serial# Instrument’s Serial Number
3 Date#1(MM/DD/YY) Date (Measurement #1)
4 Time#1(HH:MM:SS) Time (Measurement #1)
5 Btry#1(V) Battery Voltage (Measurement #1)
6 Flow#1(cfm) Sample Flow Rate (Measurement #1) in cfm
7 Back#1(%) Background Gas Level (Measurement #1) in %
8 Leak#1(%) Sample Leak Rate (Measurement #1) in %
9 Leak#1(cfm) Leak Rate of Component Under Test (Measurement #1) in
cfm
10 Date#2(MM/DD/YY) Date (Measurement #2)
11 Time #2(HH:MM:SS) Time (Measurement #2)
12 Btry#2(V) Battery Voltage (Measurement #2)
13 Flow#2(cfm) Sample Flow Rate (Measurement #2) in cfm
14 Back#2(%) Background Gas Level (Measurement #2) in %
15 Leak#2(%) Sample Leak Rate (Measurement #2) in %
16 Leak#2(cfm) Leak Rate of Component Under Test (Measurement #2) in
cfm
17 Leak#1-#2(%) Percent Difference Between Leak Measurements #1 and #2
18 Error Codes Error Codes identifying problems that occurred during the
test (refer to Section 6.3 Error Codes in Saved Test Records)
19 Barcode# Barcode Type (UPC, EAN, Code 128, Cadabar)
20 Barcode Symbology Barcode Number Scanned
21 GPS Latitude(deg) Latitude of Instrument in Degrees
22 GPS Longitude(deg) Longitude of Instrument in Degrees
23 GPS Altitude(ft) Altitude of Instrument in Meters
24 Test Description Test ID Information (refer to Section 3.15 Access Test IDs)
