Bacharach HI FLOW Sampler User Manual

Operation Hi Flow Sampler
Instruction 0055-9017
30
4. From the High Flow Sampler’s Expanded Main Screen, start the
download process by selecting Menu > Access Test IDs > Send Test
IDs.
1 1 / 2 2 / 0 4 0 9 : 4 5 : 3 0
S e l e c t T e s t I D s
E d i t T e s t I D s
S e n d T e s t I D s
E r a s e T e s t I D s
[ 0 0 0 4 ] ( A ) S - -
Observe that the Hi Flow’s LCD displays the message “Sending record
x of y @ 115.2kbps,” where “x” is the current record being sent and
“y” is the number of records in memory. Also observe that
HyperTerminal displays the data as its being received.
1 1 / 2 2 / 0 4 0 9 : 4 5 : 3 0
S e n d i n g r e c o r d
x o f y
@ 1 1 5 . 2 k b p s
[ 0 0 0 4 ] ( A )
S - -
5. After all data has been transmitted, stop HyperTerminal from
capturing data by clicking Transfer > Capture Text > Stop.
6. The saved data can now be viewed on the computer using any
program capable of displaying “txt” files.
3.17.4 Erase Test IDs
Erase all Test ID information and reset the Test ID index back to 0001 as
follows:
1. From the Expanded Main Screen, select Menu > Access Test IDs >
Erase Test IDs.
1 1 / 2 2 / 0 4 0 9 : 4 5 : 3 0
S e l e c t T e s t I D s
E d i t T e s t I D s
S e n d T e s t I D s
E r a s e T e s t I D s
[ 0 0 0 4 ] ( A ) S - -
