Operation Hi Flow Sampler
Instruction 0055-9017
20
3.14.2 Manual Measurement Mode
3.14.2.1 Manual 2-Stage Mode
In the Manual 2-Stage mode the user starts a measurement at a high
flow rate, waits for a stable leak rate reading, and then manually saves
the readings using the Save function. The unit then automatically lowers
the flow rate, at which time the user makes a second leak rate
measurement. After waiting for the leak rate reading to once again
stabilize, the user then manually saves all final measured and calculated
measurements in memory. This mode is used when more control of the
leak rate measurement process is required.
Select Manual 2-Stage operation as follows:
1. From the Expanded Main Screen, select Menu > Operating Mode.
1 1 / 2 2 / 0 4 0 9 : 4 5 : 3 0
C a l i b r a t i o n
S e t F l o w U n i t s
M e n u M o d e
O p e r a t i n g M o d e
A c c e s s R e c o r d s
[ 0 0 0 1 ] ( M ) S - -
2. Highlight Manual 2-Stage, and then press the I/O key.
0 2 / 2 1 / 0 3 0 9 : 4 5 : 3 0
A u t o m a t i c 2 - S t a g e
M a n u a l 2 - S t a g e
M a n u a l 1 - S t a g e
[ 0 0 0 5 ] ( M ) S - -
3. Press ESC to return to the Main Screen. Observe that (M) should
appear at the bottom of the screen
