ITEM QUANTITY THREAD DIAMETER TORQUE VALUE REMARKS
Knuckle nut 2 10 36
Tie rod lock nut 4 10 26
Front wheel nut 8 10 30
Front axle castle nut 2 14 36
Rear axle castle nut 2 14 36
Rear wheel nut 8 10 30
Engine hanger nut 4 12 34
Rear axle holder bolt 4 12 50
Drive gear bolt 2 10 34
Driven gear nut 4 10 34
Swing arm pivot bolt 1 14 50
Front suspension arm nut 4 10 36
Front / Rear cushion mounting bolt 6 10 30
Brake hose bolt 13 10 20
Brake disk mounting bolt 11 8 26
Air-bleed valve 3 5 3.5
Exhaust muffler mounting bolt 2 8 20
Exhaust muffler connection nut 2 7 20
