PAGE 25
Specifications
Fuel tank Capacity 4.75 gallons
Engine Oil Capacity 3482 ml
Engine Oil Change 3179 ml
Differential Gear Oil Capacity 350 cc’s
Differential Gear Oil Change 350 cc’s
Capacity of coolant
Engine +
Radiator 2195 ml
Clearance of throttle valve N/A 1~3 mm
Spark plug Type Type NGK CR7E
Spark plug Gap 0.7~0.8 mm
“F” Mark in idling speed N/A BTDC 20o / 1500 rpm
Full timing advanced N/A BTDC 51o / 6200 rpm
Idling speed N/A 1500rpm (+/- 100 rpm)
Cylinder compression
pressure N/A 9.2 kgf/cm2
Valve clearance N/A
(IN:0.10 +/- 0.02 mm) (EX:0.15 + / - 0.02
mm)
Tire Dimension Front AT25x8-12
Tire Dimension Rear AT25x10-12
Tire Pressure N/A 10psi ( + / - 1 psi)
Battery 12V18Ah (type : MF battery)
