PAGE 36
SERVICE MANUAL
Maintenance
Front differential oil:
CAUTION
• Be sure the differential set temperature is below 35° Celsius or 95° Fahrenheit.
• Oil Standard: SAE #90 hypoid gear oil
• Oil Capacity: 300 c.c.
• Remove the under cover
• Place an oil pan below the differential set case.
Filler Nut ————————————————————
• Remove drain bolt, filler nut and drain oil out.
• Tighten the drain bolt to specified torque.
• Pour the oil through the filler hole.
• Tighten the filler cap to the specified torque
Oil Drain Bolt ——————————————————
• Drain Bolt: 24 ft.lbs
• Oil Filler Unit: 26.5 ft.lbs
