SPECIFICATIONS
1-1/2" to 12" Meters
Turbo Series
Model
160
1-1/2" (40 mm)
200
2" (50 mm)
450
3" (80 mm)
1000
4" (100 mm)
2000
6" (150 mm)
3500
8" (200 mm)
5500
10" (250 mm)
6200
12” (300 mm)
Meter Flanges
AWWA 125
Pound Class
Elliptical Elliptical or Round Round Round Round Round Round
Round
AWWA 125 lb
class
Typical
Operating Range
(100% ± 1.5%)
4…200 gpm
(0.9…45.4 m
3
/h)
4…310 gpm
(0.9…70.4 m
3
/h)
5…550 gpm
(1.1…124.9 m
3
/h)
10…1250 gpm
(2.3…284 m
3
/hr)
20…2500 gpm
(4.5…568 m
3
/h)
30…4500 gpm
(6.8…1022 m
3
/h)
50…7000 gpm
(11.4…1590 m
3
/h)
90…8800 gpm
(20.5…1998 m
3
/h)
Typical Low Flow
(95% min.)
2.5 gpm (0.6 m
3
/h) 2.5 gpm (0.6 m
3
/h) 4 gpm (0.9 m
3
/h) 6 gpm (1.4 m
3
/h) 12 gpm (2.7 m
3
/h) 20 gpm (4.5 m
3
/h) 30 gpm (6.8 m
3
/h)
65 gpm
(14.8 m
3
/h)
Max. Continuous
Flow
160 gpm
(36 m
3
/h)
200 gpm
(45.4 m
3
/h)
450 gpm
(102.2 m
3
/h)
1000 gpm
(227.1 m
3
/h)
2000 gpm
(454 m
3
/h)
3500 gpm
(795 m
3
/h)
5500 gpm
(1250 m
3
/h)
6200 gpm
(1408 m
3
/h)
Maximum
Intermittent
Flow
200 gpm
(45.4 m
3
/h)
310 gpm
(70.4 m
3
/h)
550 gpm
(124.9 m
3
h)
1250 gpm
(284 m
3
h)
2500 gpm
(568 m
3
/h)
4500 gpm
(1022 m
3
/h)
7000 gpm
(1590 m
3
h)
8800 gpm
(1988 m
3
/h)
Pressure Loss at
Max. Continuous
Flow
3.8 psi (0.26 bar) 3.1 psi (0.21 bar) 1.8 psi (0.12 bar) 7.3 psi (0.50 bar) 4.8 psi (0.33 bar) 2.5 psi (0.17 bar) 1.6 psi (0.11 bar) 0.8 psi (0.05 bar)
Pressure Loss at
Max. Continuous
Flow: With
Integral Strainer
9.9 psi (0.68 bar) 8.3 psi (0.57 bar) 5 psi (0.43 bar) 17.8 psi (1.2 bar) —
Max. Operating
Pressure
150 psi (10 bar)
Max. Operating
Temperature
120° F (49° C)
Optional Integral
Strainer
Built into inlet end.
Removable cover plate permits access to strainer for cleaning.
—
Optional
External Strainer
— Available for Models 200, 450, 1000, 2000, 3500, 5500 and 6200.
Test Plug Standard with integral strainer; optional for other models. Optional for Models 2000 and 3500. —
Materials
Meter Housing Lead-free alloy (EXCEPTION: Model 6200 meter housing is blue epoxy-coated cast iron)
Turbo Head Lead-free alloy
Nose Cone & Straightening Vanes Thermoplastic
Rotor Thermoplastic
Rotor Radial Bearings Lubricated thermoplastic
Rotor Thruster Bearing Sapphire jewels
Rotor Bearing Pivots Passivated 316 stainless steel
Calibration Mechanism Stainless steel & thermoplastic
Magnet Ceramic
Trim Stainless steel
Register Housing & Cover Thermoplastic or bronze
Optional Strainer and Trim Stainless steel
