16" and 20" Meters
Turbo Series Model
6600
16" (400 mm)
10000
20" (500 mm)
Meter Flanges Raised-Face Round Raised-Face Round
Typical Operating Range (100% ± 1.5%) 150…13,200 gpm (34.1…3000 m
3
/h) 300…19,800 gpm (68.1…4500 m
3
/h)
Typical Low Flow (95% minimum) 130 gpm (29.5 m
3
/h) 200 gpm (45.4 m
3
/h)
Maximum Continuous Flow 6600 gpm (1500 m
3
/h) 10,000 gpm (2270 m
3
/h)
Maximum Intermittent Flow 13,200 gpm (3000 m
3
/h) 19,800 gpm (4500 m
3
h)
Pressure Loss at Maximum Continuous Flow 0.5 psi (0.03 bar) 0.5 psi (0.03 bar)
Maximum Operating Pressure 150 psi (10 bar) 150 psi (10 bar)
Maximum Operating Temperature 120° F (49° C) 120° F (49° C)
Materials
Meter Housing Blue epoxy-coated cast iron
Turbo Head Cast iron
Nose Cone & Straightening Vanes Thermoplastic
Rotor Thermoplastic
Rotor Radial Bearings Lubricated thermoplastic
Rotor Thruster Bearing Sapphire jewels
Rotor Bearing Pivots Passivated 316 stainless steel
Calibration Mechanism Stainless steel & thermoplastic
Magnet Ceramic
Register Housing & Cover Thermoplastic or bronze
Trim Stainless steel
Specications
RTS-UM-00380-EN-09 Page 19 January 2015
