6 Technical Data
BaehrTec A1200
Medical device
Class 2A according to EU Directive 93/42
Medical devices
EMC test
Under EN 60601-1
Operating voltage
110 – 240 V AC voltage
Frequency
50 – 60 Hz
Micromotor speed range
6,000 – 35,000 rpm adjustable
Accuracy of the speeds
6,000 – 10,000 rpm, tolerance +/- 25 %
10,001 – 20,000 rpm, tolerance +/- 20 %
20,001 – 35,000 rpm, tolerance +/- 10 %
Power consumption
Max. 150 W
Micromotor voltage
24 V
Working voltage
28 V
Controller dimensions (W x D x H) in mm
(without handpiece outlet, without handpiece
button and
without filter cartridge)
220 x 195 x 110
Controller weight
Mix approx. 2,100 g
Handpiece dimensions (W x min. diameter x max.
diameter) in mm
~117 x ~19 x ~24
Handpiece weight
Mix approx. 99 g
Dust bag lid weight
Mix approx. 70 g
Ambient temperature (operation)
+10° - +35° C
Storage temperature
-5° - +40°C
Humidity
30% - 85 %
Permitted air pressure
800 hPa - 1060 hPa
Max. Vacuum (suction level 1) with filter and dust
bag
- 30 mbar +/- 25%
Max. Vacuum (suction level 1+) with filter and dust
bag
- 34 mbar +/- 25%
Max. Vacuum (suction level 2) with filter and dust
bag
- 38 mbar +/- 25%
Max. Vacuum (suction level 2+) with filter and dust
bag
- 42 mbar +/- 25%
Max. Vacuum (suction level 3) with filter and dust
bag
- 46 mbar +/- 25%
Max. Vacuum (suction level 3+) with filter and dust
bag
- 50 mbar +/- 25%
Max. Vacuum (suction level 4) with filter and dust
bag
- 54 mbar +/- 25%
Max. Vacuum (suction level 4+) with filter and dust
bag
- 58 mbar +/- 10%
Max. Vacuum (suction level 5) with filter and dust
bag
- 62 mbar +/- 10%
Max. Vacuum (suction level 5+) with filter and dust
bag
- 66 mbar +/- 10%
Max. Vacuum (suction level 6) with filter and dust
bag
- 70 mbar +/- 10%
Fuse
2X microfuse, 3.15 A delay (Type H)
IP Protection Class 30
Not protected against water
Protection against ingress of solid foreign
objects with a diameter > than 2.5 mm
Volume
Measurement conditions:
Device on foam pad (20 mm) from the front;
distance 1m; dust bag used; turbine protection filter
inserted; filter cartridge installed, handpiece
displaced 1m from the control unit and covered.
Extracted air flows freely, not discharging in the
direction of the sound-level measurement device.
Handpiece speed: 6,000 rpm
45 db to 53 db +/- 10%
