4.4 Description of suction system
When developing the suction system of the BaehrTec A1200/A2000 we have placed a great
deal of emphasis on operating safety and operating speed.
We would therefore like first and foremost to give you an insight into the operation of the
suction system.
It is possible to work with the handpiece motor switched on if the suction is
disabled.
However, it is not possible to work with the suction enabled, if the handpiece
motor is not running.
As soon as the handpiece motor is in operation, the suction will also always
be turned on automatically (barely noticeable).
We have deliberately chosen to do this because this prevents the handpiece
from becoming warm and also ensures that dust created when working is
suctioned off to a minimum.
If you do not turn on the suction yourself, we shall describe this in the
following as deactivated suction. Please be aware that this is always
running, even if you have not turned it on.
You can set the currently selected suction level using the button (20) at any time so that it is
"Not ready for operation" or "Ready for operation".
"Not ready for operation" means that the suction is not activated while the handpiece motor
is running. This will be indicated on the display if the bars in the bar graph are presented as
transparent (= suction not ready for operation).
"Ready for operation" means that the suction is activated while the handpiece motor is
running. This will be indicated on the display if the bars in the bar graph are filled blue (=
suction ready for operation).
If you press button (20) while the handpiece motor is running, the suction will immediately be
activated/deactivated.
If you press button (20) while the handpiece motor is not running, the suction will be turned
on or it will remain turned off once you turn on the handpiece motor.
