Operating Manual BaehrTec A1200 / A2000
English – V100 - Date 09/2017 Page 61/64
Guidelines and MANUFACTURER statement – ELECTROMAGNETIC EMISSION
The model BaehrTec A1200/A2000 is intended for use in the ELECTROMAGNETIC ENVIRONMENTS specified below. The
customer or end user
N11)
of the model BaehrTec A1200/A2000 should ensure it is used in such an environment.
Emission measurements
Compliance
ELECTROMAGNETIC ENVIRONMENT – Guidelines
HF emissions
according to CISPR 11
Group 1
The model BaehrTec A1200/A2000 uses HF energy exclusively
in its internal FUNCTION. That means that its HF emission is
very low and it is unlikely that adjacent electronic devices will
suffer any interference.
The model BaehrTec A1200/A2000 is intended for use in all
facilities including living areas and also that are connected to a
PUBLIC POWER SUPPLY that include buildings that are used
for residential purposes.
HF emissions
according to CISPR 11
Class B
Harmonics
under IEC 61000-3-2
Class A
Voltage fluctuations/
flicker under IEC 61000-3-3
Fulfilled
N11)
National footnote: Here, user refers to a "RESPONSIBLE ORGANISATION".
Guidelines and MANUFACTURER DECLARATION – ELECTROMAGNETIC STABILITY
The model BaehrTec A1200/A2000 is intended for use in the ELECTROMAGNETIC ENVIRONMENTS specified below. The
customer or user
N13)
of the model BaehrTec A1200/A2000 should ensure that it is used in such an environment.
STABILITY
TESTS
IEC 60601-
TEST LEVEL
COMPLIANCE
LEVEL
ELECTROMAGNETIC
ENVIRONMENT –
GUIDELINES
ELECTROSTATIC
DISCHARGE (ESD)
under IEC 61000-4-2
± 6 kV
Contact discharge
± 8 kV
Air discharge
± 6 kV
Contact discharge
± 8 kV
Air discharge
Floorings should be made
of wood or concrete or
covered with tiles. If the
floor is covered with
synthetic material, the
relative humidity must be
at least 30 %.
Electrical
electric
disturbance variables/bursts
according to IEC 61000-4-4
± 2 kV
For power supply lines
± 1 kV
For input and
output lines
± 2 kV
For power supply lines
± 1 kV
For input and
output lines
The quality of the supply
voltage should be to the
standard
of a typical
commercial or hospital
environment.
Surge voltages
under IEC 61000-4-5
± 1 kV
Voltage phase
conductor -
phase conductor
± 2 kV
Voltage phase
conductor -
earth
± 1 kV
Voltage phase conductor -
phase conductor
± 2 kV
Voltage phase conductor -
earth
The quality of the supply
voltage should be to the
standard of a typical
commercial or hospital
environment.
Voltage dips,
Short interruptions
and fluctuations in the
supply voltage
according to IEC 61000-4-11
< 5 % U
T
for 1/2 period
(> 95% dip)
40 % U
T
for 5 periods
(60 % dip)
70 % U
T
for 25 periods
(30 % dip)
< 5 % U
T
for 5 s
(> 95% dip)
< 5 % U
T
for 1/2 period
(> 95% dip)
40 % U
T
for 5 periods
(60 % dip)
70 % U
T
for 25 periods
(30 % dip)
< 5 % U
T
for 5 s
(> 95% dip)
The quality of the supply
voltage should be to the
standard of a typical
commercial or hospital
environment.
We recommend powering
the model BaehrTec
A1200/A2000 with a
interruption-
free power
supply or a battery, should
the user of the model
BaehrTec A1200/A2000
FUNCTION also require
continued FUNCTION
also when interruptions in
the power supply occur.
Magnetic field at a supply
frequency of
(50/60 Hz)
under IEC 61000-4-8
3 A/m
3 A/m
The magnetic fields of
both power frequencies
should be to the standard
of a typical commercial or
hospital environment.
N13)
National footnote: Here, user refers to a "RESPONSIBLE ORGANISATION".
