232 Fuse replacement
D50
5
Emergency handling
No.
Level
Protection circuit
RRY- 11
-
Front left fog lamp relay
RF01
30A
Front left window
RF02
30A
Front right window
RF03
20A
Power lock
RF04
15A
Reserved
RF05
15A
POWER-C-LIGHTING2
RF06
30A
AM1
RF07
20A
AM2
RF08
5A
Reserved
RF09
10A
Front left fog lamp
RF10
10A
Reserved
RF11
10A
Reserved
RF12
5A
EMS
RF13
5A
TCU power
RF14
5A
ISSOFF/TCU/BCM/ PEPS
RF15
5A
Reserved
RF16
7.5A
brake switch
No.
Level
Protection circuit
RF17
15A
Reserved
RF18
5A
Reserved
RF19
5A
Reserved
RF20
7.5A
RLS
RF21
10A
Reserve lamp
RF22
5A
BCM ACC power
RF23
15A
Cigarette power
RF24
5A
Reserved
RF25
15A
Radio
RF26
20A
Sunroof motor
RF27
15A
power alarm
RF28
7.5A
Trunk lamp
RF29
7.5A
ESCL IMMO
RF30
7.5A
PEPS
RF31
10A
PEPS
RF32
10A
QCM
RF33
5A
Rear view mirror heating
RF34
30A
Rear window heating
RF35
7.5A
Right DRL
No.
Level
Protection circuit
RF36
7.5A
Rear fog lamp
RF37
10A
Front right fog lamp
RF38
10A
Reserved
RF39
15A
Reserved
RF40
15A
Front passenger seat heat
RF41
5A
Reserved
RF42
5A
A/C feedback signal
RF43
20A
Driver seat heating
RF44
30A
Reserved
RF45
30A
Reserved
RF46
15A
Reserved
RF47
10A
Airbag
RF48
15A
Spare
RF49
15A
Spare
