SPECIFICATIONS
1 - 8 WBPEEUI240755B0
®
Analog I/O
(continued)
Analog outputs 2, 4-20 mA or 1-5 VDC
Output load - current load 600
Ω/
600
mH (maximum)
Output load - voltage load >1 k
Ω
D/A resolution 10 bits for analog outputs
Analog accuracy
Input at 25°C (77°F) standard
condition
Terminal based linearity
±
0.03% of full scale range
Repeatability
±
0.03% of full scale range
Deadband
±
0.03% of full scale range
Accuracy
±
0.1% of full scale range
Output at 25°C (77°F)
standard condition
Terminal based linearity
±
0.1% of full scale range
Repeatability
±
0.05% of full scale range
Accuracy
±
0.15% of full scale range (voltage mode)
±
0.25% of full scale range (current mode)
Temperature effect
0° to 70°C (32° to 158°F)
±
0.002% of full scale range/°C
Input cross talk rejection
(channel to channel)
50 db (min.) at 25°C (77°F)/-78 db (typ) at 25°C (77°F)
Mounting Occupies one slot in a standard INFI 90 OPEN module mounting
unit (MMU)
Environmental
Ambient temperature
(per IEC-68-2-1, 2,14)
Temperature rating within the cabinet or enclosure applies. INFI 90
OPEN internal cabinet rating: 0° to 70° C (32° to 158° F)
Relative humidity
(per IEC68-2-3)
5% to 95% up to 55°C (131°F) (noncondensing)
5% to 45% at 70°C (158°F) (noncondensing)
Pollution degree: 1 (no condensation)
Atmospheric pressure Sea level to 3 km (1.86 miles)
Air quality (per ISA S71.04,
Class LA, LB, LC - level 1)
Noncorrosive
Table 1-5. Specifications
(continued)
Property Characteristic/Value
