INTRODUCTION
SPECIFICATIONS
WBPEEUI240755B0 1 - 9
Isolation
(per IEC 1010-1, IEC 255, IEC 60)
Channel to channel and channel to
logic
Electromagnetic compatibility
Electrostatic discharge
(IEC 1000-4-2, EN 61000-4-2)
Contact: ±6 kV
Air: ±8 kV
Magnetic and electromagnetic fields
Power frequency magnetic
field
(IEC 1000-4-8, EN 61000-4-8)
Continuous: 30 A/m (rms)
Short duration: 300 A/m (rms)
Pulse magnetic field
(IEC 1000-4-9, EN 61000-4-9)
Peak value: 300 A/m
Table 1-5. Specifications
(continued)
Property Characteristic/Value
Test Common Mode
Normal
Mode
Digital Input
Insulation resistance
(100/500 VDC)
100 M
Ω
N/A
Dielectric VAC (45 to 65 Hz) or VDC 1.4 kV rms/1
min. or 1.95 kV
DC/1min.
N/A
Impulse voltage (1.2/50 µS) ±2.55 kVp ±1 kVp
Digital Output
Insulation resistance
(100/500 VDC)
100 M
Ω
N/A
Dielectric VAC (45 to 65 Hz) or VDC 1 kV rms/1 min.
or 1.5 kV DC/
1min.
N/A
Impulse voltage (1.2/50 µS) ±2 kVp ±1 kVp
Analog Input/Output
Insulation resistance
(100/500 VDC)
N/A N/A
Dielectric VAC (45 to 65 Hz) or VDC N/A N/A
Impulse voltage (1.2/50 µS) N/A ±1 kVp
Test Common Mode
Normal
Mode
Voltage/current surge (1.2/50 µS to
8/20 µS )
(IEC 1000-4-5, EN 61000-4-5)
±2 kVp ±1 kVp
Fast transient bursts
(IEC 1000-4-4, EN 61000-4-4)
±2 kVp N/A
Damped oscillatory wave, 0.1 MHz
and 1 MHz
(IEC 1000-4-12, EN 61000-4-12)
±2 kVp ±1 kVp
Ring wave
(IEC 1000-4-12, EN 61000-4-12)
±2 kVp ±1 kVp
