8.1.4 Customer supplied 24VDC supply input
24VDC
(Catalog number MDHxxxxx-xxx3)
Unit 2.5A 5A 7.5A 15A 20A 27.5A
Nominal input voltage
VDC
24
Minimum input voltage 20.4
Maximum input voltage 28.8
Maximum ripple % ±10
Maximum continuous current
@24VDC
A 1.75
Power on surge current
@24VDC, 100ms
A 4
8.1.5 Regeneration
115VAC (Catalog number MDH1...) Unit 2.5A 5A 7.5A
Switching threshold VDC on: 188-195, of f: 183-188
Nominal power (10% power cycle) kW 0.25
Peak power (10% power cycle) kW 2.7
Maximum regeneration
switching current
A
RMS
10
Maximum load inducta nce μH 100
*Note: 2.5A models (MDH1A02xx -xxxx) contain an internal 175Ω, 20W resistor.
5A models (MDH1A05xx-xxxx) contain an internal 90Ω, 40W resistor .
230VAC single-phase models
(Catalog number MDH2...)
Unit 2.5A 5A 7.5A
Switching threshold VDC on: 373-383, of f: 362-372
Nominal power (10% power cycle) kW 0.25
Peak power (10% power cycle) kW 2.7
Maximum regeneration
switching current
A
RMS
10
Maximum load inducta nce μH 100
*Note: 2.5A models (MDH2A02xx -xxxx) contain an internal 175Ω, 20W resistor.
5A models (MDH2A05xx-xxxx) contain an internal 90Ω, 40W resistor .
