Specifications 8-7MN1901
8.1.7 Analog input (X4)
All models Unit All models
Type Differential
Common mode volt a ge range VDC ±10
Common mode rejection dB 40
Input impedance kΩ >5
Input ADC resolution bits 14
(includes sign bit)
Equivalent resolution mV ±1.2
Sampling interval
Software (Mint programs)
Demand reference signal
μs
500
500
8.1.8 Analog outputs (X4)
All models Unit All models
Type Bipolar
Output voltage range VDC ±10
Output current (max) mA 1
Output DAC resolution bit s 8
(includes sign bit)
Equivalent resolution mV ±78
Update interval
Software (Mint programs)
DAC monitoring
Immediate
1ms or 2ms (selectable)
