www.bal dormotion.com
Input / Output 4-5MN1901
AIN1
1kΩ, 0.25W
potentiometer
(ADC.1)3
2
X4
1.5kΩ, 0.25W
0V
+24VDC
6
Figure 29 - Typical input circuit to provide 0-10V (approx.) input from a 24V source
