7．EtherNet/IP Connection Procedure
30
7.3.3. Transferring the Project Data
Go online with Sysmac Studio and transfer the project data to the Controller.
Regardless of the operating mode of the CPU Unit, devices or machines may
perform unexpected operation when you transfer any of the following data from
Sysmac Studio: a user program, configuration data, setup data, device
variables, or values in memory used for CJ-series Units.
Always confirm safety at the destination node before you transfer the project
data.
1
Turn ON Controller.
2
Select Check All Programs
from the Project Menu.
3
The Build Tab Page is
displayed.
Check that "0 Errors" and "0
Warnings" are displayed.
4
Select Rebuild Controller
from the Project Menu.
5
The dialog box on the right is
displayed. Check the contents
and click Yes.
6
Check that "0 Errors" and "0
Warnings" are displayed on
the Build Tab Page.
7
Select Communications
Setup from the Controller
Menu.
