Balluff BNI EIP-50 105-Z015 Series User Manual

7．EtherNet/IP Connection Procedure
31
8
The Communications Setup
Dialog Box is displayed.
Check that the Direct
connection via USB Option is
selected in the Connection
type Field.
Click OK.
9
Select Online from the
Controller Menu.
If a confirmation dialog box is
displayed, check the contents
and click Yes.
*The contents of the dialog box
vary depending on the status
of Controller. Check the
contents and click on an
appropriate button to proceed
with the processing.
10
When an online connection is
established, a yellow line is
displayed under the toolbar.
Additional Information
For details on the online connections to the Controller, refer to Section 6. Online Connections
to a Controller of the Sysmac Studio Version 1 Operation Manual (Cat. No. W504).
11
Select Synchronize from the
Controller Menu.
