BNI_EIP_508_Port_6_Data
All I/O Data Associated
with IO-Link Port 6
IO_Link_Port_Data Port6_Data
BNI_EIP_508_Port_7_Data
All I/O Data Associated
with IO-Link Port 7
IO_Link_Port_Data Port7_Data
BNI_EIP_508_Port_8_Data
All I/O Data Associated
with IO-Link Port 8
IO_Link_Port_Data Port8_Data
Mapped_BNI_EIP_508_Data
All Unique data
associated with BNI
EIP-508 module
UDT_BNI006A_50_31_040 Mapped_Master_Data
Note that in this example, Module_Name has been defined in the I/O Configuration Tree as
Balluff_IO_Link_Master.
