1.1 Validity
This guide describes the construction, function and setup
options for the BTL7 Micropulse Transducer with
PROFINET interface. It applies to types
BTL7-V50T-M____-P-C003 (see Type code breakdown
on page17).
The guide is intended for qualified technical personnel.
Read this guide before installing and operating the
transducer.
1.2 Symbols and conventions
Individual instructions are indicated by a preceding
triangle.
► Instruction 1
Action sequences are numbered consecutively:
1. Instruction 1
2. Instruction 2
Note, tip
This symbol indicates general notes.
1.3 Scope of delivery
– BTL7 transducer
– Mounting clamps with insulating sleeves and screws
– Condensed guide
The magnets are available in various models
and must be ordered separately.
1.4 Approvals and markings
UL approval
File no.
E227256
Certified in accordance with
Conformance ClassA, B and C.
The CE Mark verifies that our products
meet the requirements of EU Directive
2004/108/EC (EMC Directive).
The transducer meets the requirements of the following
generic standards:
– EN61000-6-1 (noise immunity)
– EN61000-6-2 (noise immunity)
– EN61000-6-3 (emission)
– EN61000-6-4 (emission)
and the following product standard:
– EN61326-2-3
Emission tests:
– RF emission
EN55016-2-3 (industrial and residential areas)
Noise immunity tests:
– Static electricity (ESD)
EN 61000-4-2 Severity level3
– Electromagnetic fields (RFI)
EN 61000-4-3 Severity level3
– Electrical fast transients (burst)
EN 61000-4-4
Severity level3
– Surge
EN 61000-4-5 Severity level2
– Conducted interference induced
by high-frequency fields
EN 61000-4-6 Severity level3
– Magnetic fields
EN 61000-4-8 Severity level4
More detailed information on the guidelines,
approvals, and standards is included in the
declaration of conformity.
