1.19 Appendix A. Specific Camera / Sensor Data 223
"TriggerSelector =
FrameStart"
"TriggerMode = On"
"TriggerSource =
<desired Line>"
"TriggerActivation =
AnyEdge"
"ExposureMode = Timed"
OnAnyEdge Start the exposure of a frame when
the trigger input level changes from
high to low or from low to high.
Device Feature And Property List (p. 223)
1.19.1.1.4.4 Device Feature And Property List
1.19.1.1.5 BVS CA-BN2-0124ZG (12.4 Mpix [4112 x 3008])
1.19.1.1.5.1 Introduction The sensor uses a global shutter, i.e. light exposure takes place on all pixels in paral-
lel, although subsequent readout is sequential.
Feature Description
Manufacturer Sony
Sensor name IMX253
Max. frames per second 64.6
Device Structure CMOS image sensor
SNR
max
[dB]
1/
40,1
DNR (normal / HDR) [dB]
1/
71,1 / -
Image size 1.1
Number of effective pixels 4112 (H) x 3008 (V)
Unit cell size 3.45µm (H) x 3.45µm (V)
ADC resolution / output 12 bit → 8/10/(12)
1
Measured accord. to EMVA1288 with gray scale version of the camera
1.19.1.1.5.2 Spectral Sensitivity
MATRIX VISION GmbH
