1.19 Appendix A. Specific Camera / Sensor Data 225
"TriggerSelector =
AcquisitionActive"
"TriggerMode = On"
"TriggerSource =
<desired Line>"
"TriggerActivation =
LevelLow"
"ExposureMode = Timed"
OnLowLevel Start an exposure of a frame as
long as the trigger input is below
the trigger threshold. (No Frame←-
Trigger!)
"TriggerSelector =
AcquisitionActive"
"TriggerMode = On"
"TriggerSource =
<desired Line>"
"TriggerActivation =
LevelHigh"
"ExposureMode = Timed"
OnHighLevel Start an exposure of a frame as
long as the trigger input is above
the trigger threshold. (No Frame←-
Trigger!)
"TriggerSelector =
FrameStart"
"TriggerMode = On"
"TriggerSource =
<desired Line>"
"TriggerActivation =
FallingEdge"
"ExposureMode = Timed"
OnFallingEdge Each falling edge of trigger signal
acquires one image.
"TriggerSelector =
FrameStart"
"TriggerMode = On"
"TriggerSource =
<desired Line>"
"TriggerActivation =
RisingEdge"
"ExposureMode = Timed"
OnRisingEdge Each rising edge of trigger signal
acquires one image.
"TriggerSelector =
FrameStart"
"TriggerMode = On"
"TriggerSource =
<desired Line>"
"TriggerActivation =
AnyEdge"
"ExposureMode = Timed"
OnAnyEdge Start the exposure of a frame when
the trigger input level changes from
high to low or from low to high.
Device Feature And Property List (p. 225)
1.19.1.1.5.4 Device Feature And Property List
1.19.1.1.6 BVS CA-BN2-0246AG (24.6 Mpix [5328 x 4608])
1.19.1.1.6.1 Introduction The sensor uses a global shutter, i.e. light exposure takes place on all pixels in paral-
lel, although subsequent readout is sequential.
