B&C Electronics CL 7685
Operator’s Manual - Rev. C - 05/05
- 18 –
4 KEYBOARD
KEY SYMBOL FUNCTION
ù
[MODE]
- allows the operator to go to the next Display
- allows to go back to the main Display. The eventual
new parameter values will not be memorized
§
[CAL]
- allows the access of calibration sequences
ò
[/\]
- allows to increase the displayed parameters
- allows to choose between different functions
ç
[\/]
- allows to decrease the displayed parameters
- allows to choose between different functions
£
[ENT]
- allows to enter the selected data and to return to the
main Display D0
