B&C Electronics CL 7685
Operator’s Manual - Rev. C - 05/05
- 32 –
7 CONFIGURATION
The following operations are possible:
- Keyboard locked/unlocked selection.
- Display contrast selection.
- Access number insertion.
1. [MODE] to go to Display D8
_
D8 | Configuration |
2. [CAL] to access the configuration sequences
7.1 KEYBOARD LOCKED/UNLOCKED
_ _
| KB UNLOCKED | | KB LOCKED |
keyboard unlocked keyboard locked
[MODE] to go to D8
3. [/\] [\/] to select one of the two options (locked/unlocked)
4. [ENT] to confirm and to go to the next step
7.2 LCD DISPLAY CONTRAST
_
|LCD contrast: 4 |
[MODE] to go to D8
1. [/\] [\/] to select the contrast from 0 to 7
2. [ENT] to confirm and to go to the access number insertion.
