B&C Electronics CL 7685
Operator’s Manual - Rev. C - 05/05
- 38 –
7.20 ALARM ON SET-POINT B
_ _
|AL SET B: ON | |AL SET B: OFF |
Active keys: [MODE] - [/\] [\/] - [ENT]
1. Two possible alternative A or B.
1A. "OFF" alarm function not activated
1B. "ON". alarm function activated
2B. to insert the activation time for Set-point B
_
|TIME SET B: 10 m|
10 m: activation time
Active keys: [MODE] - [/\] [\/] - [ENT]
7.21 ALARM RELAY CONTACT FUNCTION
Two possible alternative:
_ _
|AL RELAY: ACT | |AL RELAY: DEA |
ACT: active alarm = relay activated
DEA: active alarm = relay deactivated
Active keys: [MODE] - [/\] [\/] - [ENT]
7.22 CLEANING FUNCTION
_ _
|CAL CF:DISABLED | |CAL CF:MANUAL |
_
|CAL CF:AUTO
|
Active keys: [MODE] - [/\] [\/] - [ENT]
7.23 CLEANING TIME (RELAY D ON)
_
|CLEANING T:15.0"
|
Active keys: [MODE] - [/\] [\/] - [ENT]
