B&C Electronics CL 7685
Operator’s Manual - Rev. C - 05/05
- 34 –
7.8 CELL POLARIZATION VOLTAGE
_
|CAL POL.: -200mV|
POL.-200 mV: actual polarization voltage
This polarization voltage is calibrated during the manufacturing and it may be changed by means of
the internal trimmer marked BM(R14).
Remove the back panel to adjust the trimmer, watching the readout.
Active keys: [MODE] - [/\] [\/] - [ENT]
7.9 CALIBRATION MODE
_
|MODE OF CAL:POST|
POST: Postponed calibration mode selected
Active keys: [MODE] - [/\] [\/] - [ENT]
7.10 TEMPERATURE COEFFICIENT
_
|CAL TC: 2.00%/°C|
2.00% / °C: Temperature coefficient value
Active keys: [MODE] - [/\] [\/] - [ENT]
7.11 INPUT RELATED TO ANALOG OUTPUT N°1 (OPTION 091.3711)
This configuration is available only when the dual output option 091.3711 is installed.
The input corresponding to the output range is selectable as Cl
2
(ClO
2
/O
3
) or Temperature for the two
outputs.
_
|CAL OUT1: ppm | (°C)
PPM: input range selected for analog output N°1
Active keys: [MODE] - [/\] [\/] - [ENT]
