B&C Electronics CL 7685
Operator’s Manual - Rev. C - 05/05
- 37 –
7.17 SET-POINT B OPERATING MODE
_
|SET B ACT:On/Off| (PWM-PFM)
On/Off, PWM, PFM: set-point B operating mode
Active keys: [MODE] - [/\] [\/] - [ENT]
7.18 SET-POINT B FUNCTION
_ _
|SET B F. : LO | |SET B F. : HI |
LO: minimum (relay activated for meas. below set-point)
HI: maximum (relay activated for meas. above set-point)
Active keys: [MODE] - [/\] [\/] - [ENT]
7.19 ALARM ON SET-POINT A
_ _
|AL SET A: ON | |AL SET A: OFF |
Active keys: [MODE] - [/\] [\/] [ENT]
1. Two possible alternative A or B.
1A. "OFF" alarm function not activated
1B. "ON" alarm function activated
2B. to insert the activation time for set-point A
_
|TIME SET A: 10 m
|
10 m: activation time
Active keys: [MODE] - [/\] [\/] - [ENT]
