B&C Electronics CL 7685
Operator’s Manual - Rev. C - 05/05
- 8 –
Options
091.3711 Dual isolated and programmable output
The operator may select an output for Temperature.
091.404 24 VAC power supply.
091.701 RS232 isolated output
The output sends the data (PPM,°C) to the serial port of the computer.
1.2 PHYSICAL DESCRIPTION
The controller enclosure is designed for surface or panel mounting.
It consists of an anodized aluminium case built according to the standard DIN 43700, with an
aluminium panel coated with scratch-proof and non-corrosive polycarbonate membrane.
A transparent waterproof front door SZ 7601 can be added to the housing, in order to protect the unit
from excessive moisture or corrosive fumes.
Signal and power cable connections are made by using two special extractable terminal blocks
placed in the back of the instrument.
This makes wiring, installation and general maintenance of the probes and other devices easier.
The package is supplied complete with fixing clamps for panel-mounting.
