B&C Electronics CL 7685
Operator’s Manual - Rev. C - 05/05
- 29 –
PWM function
The instrument will show the following display:
_
|CAL SA BP: 0.10 |
BP 0.10: actual proportional band value
[MODE] to stop the procedure and to go back to D3/D4
5C. [/\] [\/] to select the proportional band value
6C. [ENT] to confirm and to go to the selection of the pulse length value
_
|CAL SA D: 5.0/s|
D 5.0 s: actual pulse length value
[MODE] to stop the procedure and to go back to D3/D4
7C. [/\] [\/] to select the pulse length value
8C. [ENT] to confirm and to go back to D3/D4
6.5 ALARM ADJUSTMENT
The following operations are possible:
- to select the min/max alarm value
- to select the delay time value
1. [MODE] to go to
_
D5 |AL 0.0/20.0ppm| Alarm display
2. [CAL] to access the calibration sequences
_
|CAL AL L: 0.00
| Minimum alarm value calibration
L 0.00: actual minimum alarm value
[MODE] to stop the procedure and to go back to D5
3. [/\] [\/] to select the value
4. [ENT] to confirm and to go to the maximum value insertion
_
|CAL AL H:20.00 | Maximum alarm value calibration
H 20.00: actual maximum alarm value
[MODE] to stop the procedure and to go back to D5
