B&K 2245 - Examine the Project

84
Procedure:
1.
In the import dialog, click .
2. Click Add NAS.
3.
Browse to the location of the backup.
✐ Note: Your computer will need to be able to access this location.
4. Select the folder with the matching serial number of your instrument.
5. Click Select Folder.
Add an Instrument Using its IPAddress
If you want to find an instrument that is not showing up in the list of discovered instruments, such as an instrument on
another network, you can manually add the instrument to the list using its IPaddress.
✐ Note: Use this functionality to connect to your instrument remotely.
1.
In the import dialog, click .
2. Click Add instrument from IP address.
3.
Enter the IP address or host name.
Enter the IP address or host name, and if used, the password.
l For local connections, you can find the IPaddress of the instrument here:Menu > System settings > Net-
work settings > Wi-Fi settings or Ethernet settings
l For remote connections, the IP address or host name will depend on your setup. Refer to Remote Con-
nections for information about which IPaddress or host name to use
4. Click OK.
Examine the Project
The Measurement Window
The Measurement window displays the single or logged decibel (dB) levels of measured broadband and spectrum para-
meters, as well as the dB levels for statistical parameters. It includes a graph in the upper section that helps keep you ori-
ented as you view the graphs and tables in the lower section.
Switch Views
Once you select measurements in the project, you can view the measurement data as graphs or in a table.
Click to switch between the graph and table views.
Use the PC App: Examine the Project
