Bang & Olufsen BeoLink NL/ML User Manual

Setting up NL/ML Delay Box 19
! Known limitation in functionality:
No solution for option 1-1 and 2-2 (speakers on Audio Master). Use setup from Example 4 for an echo free audio source solution.
To install an NL/ML Delay Box (8052438), remember to order a SMPS adaptor.
EU SMPS: 8040002 GB SMPS: 8040004 AUS SMPS: 8040006 US SMPS: 8040008 CN SMPS: 8040200
Option settings
Living room: BeoVision 11 in option 2 and BeoSound 5 in option 0.
Bedroom: BeoPlay V1 in option 2
Kitchen: BeoVision 7 in option 6
Ofce: BeoLink Active in option 6
Delay overview
If other delay values are required according to the ML Delay setting displayed in Network Link supported products, then actual dip switch setting
can be found from this table.
Audio delay ms Comments LSB MSB 170 1 1 1 1 0
Down = 0 / Up = 1 DIP 1 DIP 2 DIP 3 DIP 4 DIP 4 181 0 0 0 0 1
10 0 0 0 0 0 191 1 0 0 0 1
21 1 0 0 0 0 202 0 1 0 0 1
31 0 1 0 0 0 213 1 1 0 0 1
42 1 1 0 0 0 223 0 0 1 0 1
53 0 0 1 0 0 234 1 0 1 0 1
63 1 0 1 0 0 245 0 1 1 0 1
74 0 1 1 0 0 255 1 1 1 0 1
85 1 1 1 0 0 266 0 0 0 1 1
95 0 0 0 1 0 277 1 0 0 1 1
106 1 0 0 1 0 287 0 1 0 1 1
117 0 1 0 1 0 298 1 1 0 1 1
127 1 1 0 1 0 309 0 0 1 1 1
138 0 0 1 1 0 319 1 0 1 1 1
149 Default setting 1 0 1 1 0 330 0 1 1 1 1
159 0 1 1 1 0 341 1 1 1 1 1
Table continues to the right..
