31R5900103 /00 C-10, C-5
Wireless transmission
protocol
IEEE 802.11 a/g/n/ac and IEEE 802.15.1
Reach Adjustable with signal strength modulation; max. 30m (100 ft) between
ClickShare Button and ClickShare Base Unit
Frequency band 2.4 GHZ and 5 GHz
Frequency band 2.4 GHZ and 5 GHz (DFS channels supported in select number of
countries)
Connections 1x Ethernet LAN 1Gbit
1x USB Type-C 2.0 (front); 1x USB Type A 2.0 (front)
Temperature range Operating: 0°C to +40°C (+32°F to +104°F)
Max: 35°C (95°F) at 3000m
Storage: -20°C to +60°C (-4°F to +140°F)
Humidity Storage: 0 to 90% relative humidity, non-condensing
Operation: 0 to 85% relative humidity, non-condensing
Anti-theft system Kensington lock
Certifications FCC/CE
Touch screen support &
Interactivity
/
Room Dock (peripheral
support)
No
Local view & moderation Local view of the room display only
Network connection LAN & WiFi
Management and reporting Yes
Warranty 1 year standard. 5 years coverage via SmartCare
* * depends on configuration, available in future firmware updates
Button
Weight 60 gr - 0.132 lb
Frequency band 2.4 GHZ and 5 GHz
Wireless transmission
protocol
IEEE 802.11 a/b/g/n/ac
Authentication protocol WPA2-PSK in stand alone mode
WPA2-PSK or IEEE 802.1X in network integration mode
Connectors USB-C type
Dimensions (HxWxD) 14.6 mm x 59.3 mm x 161.39 mm / 0.57” x 2.354” x 6.354”
Power consumption Powered over USB
5V DC
350mA Typical
500mA Maximum
C-10, C-5 Specifications
