21CLM W6
2. Introduction
Ind. Key Name Description
6 YUV Select YPbPr source
7 LENS Adjust Lens shift up/down/left/right
8 VGA 2 Select VGA 2 source
9 ENTER
Conrm selection or enter lens menu when no
menu is on
10 TEXT Text on/off
11 ASPECT Choose the desired aspect ratio
12 A IMG Force auto image adjustment
13 SHARPN Adjust the sharpness of the image
14 TINT Adjust the color balance of red and green
15 ADDRESS Select an IR address of the remote
16 COLOR Adjust color saturation of the source
17 HDMI 1 Select HDMI 1 source
18 VGA 1 Select VGA 1 source
19 S-VID Select S-VIDEO source
20 VIDEO Select VIDEO source
21 ◄►▲▼ Navigation keys
22 MENU Enter menu or one level up in menu
23 FREEZ Freeze the image
24 BRIGHT Adjust the brightness of the image
25 PAUSE Picture mute
26 CONT Adjust the contrast of the image
27 PHASE Adjust the phase of pixel sampling clock
28 PIP ON/OFF picture-in-picture
29 SWAP Swap main screen and PIP screen
