2. Display Controller installation
1
DisplayPort Connection
2
DVI-I Connection
IO-Panel for the Barco MXRT-2600
Image 2-5
MXRT-2600
1
DisplayPort #1
2
DisplayPort #2
IO-Panel for the Barco MXRT-5450 & MXRT-5550
Image 2-6
MXRT-5450 & MXRT-5550
1
Head 1- DVI-I Connection
2
Head 2- DVI-I Connection
IO-Panel for the Barco MXRT-4500, MXRT-5400, MXRT-5500 & MXRT-7400
Image 2-7
MXRT-4500, MXRT-5400, MXRT-5500 & M XRT-7400
1
DisplayPort #1
2
DisplayPort #2
3
DVI-I
