5. Driver and software features
5.8.3 Configuration
Configuring Reading Environment for Diagnostic Displays
• Use the settings QAWeb al ready has: When selected, reading environment settings for diagnostic
displays are disabled in the Barco System Settings Control Panel.
• Suggest the following settings to QAWeb: When selected, the reading environments are modifi-
able.
• White point chromaticity: This selects between clearbase, bluebase, and native white points.
• Ambient light condition: This selects the expected ambient light condition based on reading room
class.
• SteadyColor calibration: This selects the color calibration model of the SteadyColor display.
• Luminance of white: This slider sets the calibration luminance of the display.
Configuring Reading Environment for Non-Diagnostic Displays
• Select the displays: All supported non-diagnostic displays are listed in the confi guration section.
Click on the checkbox to enable the feature on that display.
• Display luminance: This slider bar sets the luminance reduction for the selected displays.
5.9 Screen Capture
5.9.1 Description
Overview
The Screen Capture feature captures the desktop into an image, including the Intuitive Workflow features,
such as SpotView.
Image 5-10
Supported display controllers
This feature is supported by MXRT-x400 and above display controllers.
5.9.2 O peration
UsingScreenCapture
The screen capture is triggered through a hotkey. The user can choose to capture the image of the display
with the cursor to the clipboard. The user can also choose to capture an image of each display to a file in
either PNG or PPM format.
