5. Driver and software features
5.5 Film Clip
5.5.1 Description
Overview
Film Clip allows the user to view a physical radiological film by using the I-Luminate feature of the disp
lay
as a virtual light box.
Image 5-6
Supported display controllers
When driven by an MXRT-x400 or later display controller, Film Clip can be enabled on the MDMG-5221
and MDMC-12133 displays.
5.5.2 O peration
Using Film Clip
The size and location of the film clip light box are programmable. It has an automatic time-out with a
programmable duration. An optional hotkey can quickly turn the light box on or off.
5.5.3 Configuration
Configuring Film Clip
• Enable Fil m Clip hotkey for these displays: All displays that support Film Clip arelistedinthe
configuration section. Click on the checkbox to launch the feature on that display with the hotkey.
• Timeout: The slider bar sets the time-out period for Film Clip mode.
• Hotkey to e nabled Film Clip: Click Clear to remove a hotkey. Click on the hotkey box to enter a new
one.
• Position: This sets the location of the light box image on enabled displays.
• Size: This sets the size of the light box image to match the physical fi lm dimensions.
5.6 FindCursor
5.6.1 Description
Overview
The FindCursor feature provides a method to quickly locate the cursor on a system with multiple displays.
Image 5-7
Supported display controllers
FindCursor is supported on all MXRT-x400 or later display controllers.
