2. Display Controller installation
2. DISPLAY CONTROLLER INSTA LLATION
2.1 Wh ich Disp lay C ontroller ?
Display Controller range
Your Barco medical display is compatible with a large range of Barco Display Controller boards. Depend-
ing on the order details, the display can be delivered with or without a Display Controller.
If you are installing a Barco Display Controller, please follow the installation instructions in this section.
Barco displays are compatible with a limited set of non-Barco display controllers. If you are installing a
non-Barco display controller, please consult its corresponding documentation.
2.2 Installing a Barco Disp lay Controller
Guidance
This chapter will guide you through the physical installation of a Barco Display Controller for your display
system.
WARNING: Wear a grounded, protective ESD strap when handling or during installation
of the Di splay Controller. Electros tatic charges can damage the Dis play Controller.
Overview
Prior to installing the Barco Display Controller(s) for your Barco Display System in your workstation, please
take a few minutes to familiarize yourself with the Display Controller(s) and the PCIe slots.
Types of Display Controllers for Barco Display Systems
The following models of Barco Display Controllers are available for your display system. Please check
which of the following models is delivered with your system and follow the corresponding installation in-
structions:
Barco Model
Compatible PCIe Slot
Barco MXRT-1450 x1
1
,x8,x16
Barco MXRT-1451 x1
1
,x8,x16
Barco MXRT-2400 x16
Barco MXRT-2500 x16
Barco MXRT-2600 x16
Barco MXRT-4500
2
x16
Barco MXRT-5400 x16
Barco MXRT-5450 x16
Barco MXRT-5500 x16
Barco MXRT-5550 x16
Barco MXRT-5600 x16
1. Recommended PCIe slot. You can also use x16 & x8 slots for x1 boards.
2. Available in limited markets
K5905271 DISPLAY CONTROLLER 27/02/2017 5
