4. Configuring Barco displays in Windows
4. CONFIGURING BARCO DISPLAYS IN
WINDOWS
4.1 Display res olution
Changing resolutions
1. Click on the Configure Displays button on the Barco System Settings Control Panel or right click on
the desktop and select Screen resolution in Windows 7 and 8.1. This will open the Windows Control
Panel shown in image 4-1. In Windows 10, right click on the desktop and select Display settings to
launch a control panel with similar functions but a different look and feel.
2. Click on the Resolution drop down box to show the list of resolutions.
3. Select the desired resolution, and click Apply.
Image 4-1
Windows Display Control Panel
In Windows 7, the maximum horizontal resolution of the desktop is 8192 pix els for a sin-
gle display controller. Your calculation should include the VirtualView display, if used.
Please refer to Microsoft Knowledge Base article 2724530.
4.2 Software rotation
Configuring screen orientation
Software rotation is only necessary for displays that do not support hardware rotation, such as MDRC
displays and some third party displays.
1. Right click on the Desktop, and select Screen Resolution in the context menu.
2. Select a Display.
3. In the Orientation drop down list, these options are available:
