6. Important information
Power consumption 72 Watt
Form factor 230.53 mm (L) x 98.34 mm (H) single PCIe slot wide
Operating system Windows 7 – 32/64-bit, Windows 8.1 – 64-bit, Windows 10 – 64-bit
Platforms Intel® and AMD architectures
Graphics accelerator
ATI FirePro
Graphics memory 1 GB GDDR5
Memory interface
128-bit
Memory bandwidth 64 GB/s
Pixel depth 32-bit pixels (supports 8-bit and 10-bit per color channel)
Electrical standard Dual-link DVI complying to v1.0
Connectors
2- DVI-I
Connectivity Dual-Link DVI Cables
Supported resolutions
Up to 6MP color and 10MP grayscale
DirectX support
Microsoft® DirectX v11.0, Vertex Shader 5.0, Pixel Shader 5.0
OpenGL support OpenGL 4.0
OpenCL support OpenCL 1.0
Approvals and compliance
FCC Part 15 Class B, CE EN 55022 Limit B, EN 55024, UL-60950-1,
BMSI CNS, CISPR- 22/24, IEC609050-1, VCCI, CSA C22.2, EU RoHS
directive (2002/95/EC), Certificate of Information & Communication
Equipment (Republic of Korea)
Operating temperature 0° to 60°C (32° to 140° F)
MXRT-5500
Product acronym MXRT-5500
Bus compatibility PCIe Gen3 x16
Power consumption 75 Watt
Form factor 184.15 mm (L) x 111 mm (H) single PCIe slot wide
Operating system Windows 7 – 32/64-bit, Windows 8.1 – 64-bit, Windows 10 – 64-bit
Platforms Intel® and AMD architectures
Graphics accelerator
ATI FirePro
Graphics memory 2 GB GDD R5
Memory interface
256-bit
Memory bandwidth 102.3 GB/s
Pixel depth 32-bit pixels (supports 8-bit and 10-bit per color channel)
Electrical standard Dual-link DVI complying to v1.0, DisplayPort complying to v1.2
Connectors
1- DVI-I, 2- DisplayPort
Connectivity Two DisplayPort to Single-Link DVI-I dongles included DisplayPort to
Dual-Link DVI-I dongle available from Barco; Part Number K9305104
Supported resolutions
Up to 6MP color and 10MP grayscale
DirectX support Microsoft® DirectX v11.1, Vertex Shader 5.0, Pixel Shader 5.0
OpenGL support OpenGL 4.2
OpenCL support OpenCL 1.2
