6. Important information
Memory interface
256-bit
Memory bandwidth
154 GB/s
Pixel depth
32-bit pixels (supports 8-bit and 10-bit per color channel)
Electrical standard DisplayPort complying to v1.2
Connectors
4- DisplayPort
Connectivity Two DisplayPort to Single-Link DVI-I dongles included DisplayPort to
Dual-Link DVI-I dongle available from Barco; Part Number K9305104
Supported resolutions Up to 6MP color and 10MP grayscale
DirectX support
Microsoft® DirectX v11.1, Vertex Shader 5.0, Pixel Shader 5.0
OpenGL support OpenGL 4.2
OpenCL support OpenCL 1.2
Approvals and compliance
FCC Part 15 Class B, CE EN 55022 Limit B, EN 55024, UL-60950-1,
BMSI CNS, CISPR- 22/24, IEC609050-1, VCCI, CSA C22.2, EU RoHS
directive (2011/65/EC), Certificate of Information & Communication
Equipment (Republic of Korea)
Operating temperature 0° to 60°C (32° to 140° F)
MXRT-7600
Product acronym MXRT-7600
Bus compatibility
PCIe Gen3 x16
Power consumption 150 Watt
Power connector
One 2x3 power connector
Form factor 248 mm (L) x 110 mm (H) single PCIe slot wide
Operating system Windows 7 – 32/64-bit, Windows 8.1 – 64-bit, Windows 10 – 64-bit
Platforms Intel® and AMD architectures
Graphics accelerator ATI FirePro
Graphics memory 8 GB GDD R5
Memory interface
256-bit
Memory bandwidth
160 GB/s
Pixel depth
32-bit pixels (supports 8-bit and 10-bit per color channel)
Electrical standard DisplayPort complying to v1.2
Connectors
4- DisplayPort
Supported resolutions
Up to 12MP color and 10MP grayscale
DirectX support
Microsoft® DirectX v11.2, Vertex Shader 5.0, Pixel Shader 5.0
OpenGL support OpenGL 4.4
OpenCL support OpenCL 1.2
Approvals and complian
ce
FCC Part 15 Class B, CE EN 55022 Limit B, EN 55024, UL-60950-1,
BMSI CNS, CISPR- 22/24, IEC609050-1, VCCI, CSA C22.2, EU RoHS
directive (2011/65/EU), Certificate of Information & Communication
Equipment (Republic of Korea)
Operating temperature 0° to 45°C (32° to 113° F)
K5905271 DISPLAY CONTROLLER 27/02/2017 51
