Bard CH Series - Figure 13 Unit Dimensions

Manual 2100-769A
Page 19 of 50
FIGURE 13
Unit Dimensions
All dimensions are in inches. Dimensional drawings are not to scale.
2.000
UV
Return Air Opening
Ventilation Air
Supply Air Opening
Inlet
Condenser Air Outlet
Cond. Air
Exhaust Air
MIS-3978 D
C. Breaker/
Disconnect
Access Panel
(Lockable)
Filter Behind Control Panel Door
Optional
Electrical
Entrance
Drain
W
G
F
High Voltage
Electrical
Entrance
Electrical
Entrance
Panel
Electric Heat
Heater Access
4° Pitch
Rain Hood
Built In
Low Voltage
Recessed
front cover
J
1.375
A
C
I
K
D
H
2.250
3.000
Mounting
Side Wall
Brackets
(Built In)
Location
Shipping
Flashing
Top Rain
DO NOT PLACE ELECTRICAL
ENTRANCES IN SHADED AREAS
ABOVE DUE TO POTENTIAL
INTERFERENCE WITH COPPER TUBING
.375
B
E
O
M
N
T
S
S
S
S
S
L
R
.375
TYP.
Width
(W)
Depth
(D)
Height
(H)
Supply Return
A B C B E F G I J K L M N O R S T U V
C36HY
C42HY
42.00 25.52 84.75 9.88 29.88 15.88 29.88 43.88 12.63 39.06 30.06 43.25 26.94 55.59 52.59 8.82 43.00 1.44 16.00 1.88 10.50 12.00
C48HY
C60HY
42.00 25.52 92.88 9.88 29.88 15.88 29.88 43.88 12.63 45.00 30.06 49.25 35.06 61.72 58.72 8.82 43.00 1.44 16.00 10.00 13.88 15.43
