Bard CH Series - Table 11 A Cooling Pressures - Full Load

Manual 2100-769A
Page 40 of 50
TABLE 11A
Cooling Pressures – Full Load
Air Temperature Entering Outdoor Coil °F
Low side pressure ± 4 PSIG
High side pressure ± 10 PSIG
Tables are based upon rated CFM (airow) across the evaporator coil. If there is any doubt as to correct operating charge
being in the system, the charge should be removed and system evacuated and recharged to serial plate charge weight.
NOTE: Pressure table based on high speed condenser fan operation. If condensing pressures appear elevated check
condenser fan wiring. See Condenser Fan Operation on page 30.
* Operating at these conditions would be outside the compressor operating envelope and is not recommended.
Model
Return Air
Temp
(DB/WB)
Pressure 75 80 85 90 95 100 105 110 115 120 125
C36HY
75/62
Suction Pressure 133 134 135 136 137 138 139 140 142 143 144
Head Pressure 300 322 346 371 397 423 451 480 509 540 572
80/67
Suction Pressure 142 143 144 145 147 148 149 150 152 153 154
Head Pressure 308 331 355 380 407 434 463 492 522 554 587
85/72
Suction Pressure 147 148 149 151 152 153 154 155 157 158 160
Head Pressure 318 342 367 394 421 449 479 509 541 573 607
C42HY
75/62
Suction Pressure 134 134 134 135 136 137 138 139 140 142 143
Head Pressure 314 333 355 377 402 427 454 483 513 545 578
80/67
Suction Pressure 143 143 144 144 145 146 147 149 150 152 153
Head Pressure 322 342
364 387 412 438 466 496 527 559 593
85/72
Suction Pressure 148 148 149 150 150 151 153 154 155 157 159
Head Pressure 333 354 376 400 426 453 482 513 545 579 614
C48HY
75/62
Suction Pressure 133 135 136 137 138 139 140 141 143 144 145
Head Pressure 305 326 348 372 397 423 451 479 509 541 573
80/67
Suction Pressure 143 144 145 146 147 149 150 151 152 154 155
Head Pressure 312 334 357 381 407 434 462 492 522 554 588
85/72
Suction Pressure 148 149 150 151 153 154 155 156 158 159 161
Head Pressure 323 346 370 395 421 449 478 509 541 574 608
C60HY
75/62
Suction Pressure 127 128 129 131 132 133 134 135 136 137
---*
Head Pressure 305 326 348 371 395 420 447 474 503 532
80/67
Suction Pressure 136 137 138 140 141 142 143 145 146 147
Head Pressure 313 335 357 381 405 431 458 486 515 546
85/72
Suction Pressure 140 142 143 145 146 147 148 150 151 152
Head Pressure 324 346 369 394 419 446 474 503 533 565
