Bard CH Series - Table 11 B Cooling Pressures - Part Load

Manual 2100-769A
Page 41 of 50
TABLE 11B
Cooling Pressures – Part Load
Air Temperature Entering Outdoor Coil °F
Low side pressure ± 4 PSIG
High side pressure ± 10 PSIG
Tables are based upon rated CFM (airow) across the evaporator coil. If there is any doubt as to correct operating charge
being in the system, the charge should be removed and system evacuated and recharged to serial plate charge weight.
NOTE: Pressure table based on high speed condenser fan operation. If condensing pressures appear elevated check
condenser fan wiring. See Condenser Fan Operation on page 30.
* Operating at these conditions would be outside the compressor operating envelope and is not recommended.
Model
Return Air
Temp
(DB/WB)
Pressure 75 80 85 90 95 100 105 110 115 120 125
C36HY
75/62
Suction Pressure 137 139 140 141 142 143 145 146 147 149 150
Head Pressure 236 273 293 315 337 360 385 410 437 465 494
80/67
Suction Pressure 147 149 150 151 152 153 155 156 158 159 161
Head Pressure 242 280 301 323 346 370 395 421 448 477 506
85/72
Suction Pressure 152 154 155 156 157 159 160 162 163 165 166
Head Pressure 251 290 311 334 358 382 408 436 464 493 524
C42HY
75/62
Suction Pressure 137 137 137 137 138 139 140 141 143 145 147
Head Pressure 241 279 299 320 343 366 390 415 442 469 498
80/67
Suction Pressure 147 146 146 147 147 148 150 151 153 155 157
Head Pressure 248 286
307 328 351 375 400 426 453 481 510
85/72
Suction Pressure 152 151 151 152 153 154 155 156 158 160 163
Head Pressure 256 296 317 340 364 388 414 441 469 498 528
C48HY
75/62
Suction Pressure 132 135 137 139 140 142 144 146 148 150 152
Head Pressure 244 276 295 314 335 357 381 405 431 459 487
80/67
Suction Pressure 141 145 146 148 150 152 154 156 158 160 162
Head Pressure 250 284 302 322 344 367 391 416 443 471 500
85/72
Suction Pressure 146 150 152 153 155 157 159 161 163 166 168
Head Pressure 259 293 313 334 356 379 404 430 458 487 517
C60HY
75/62
Suction Pressure 130 132 133 134 135 136 137 139 140 141
---*
Head Pressure 245 284 306 327 350 374 399 424 451 478
80/67
Suction Pressure 139 141 143 144 145 146 147 148 149 151
Head Pressure 251 292 313 336 359 384 409 435 462 490
85/72
Suction Pressure 144 146 148 149 150 151 152 153 155 156
Head Pressure 260 302 324 348 372 397 423 450 478 507
