Bard I30A1DA - Figure 7 B 3 Riser Application

Manual 2100-597G
Page 16 of 68
9'-5"
MINIMUM
REQUIRED
INSTALLATION
HEIGHT
CLEARANCE RECOMMENDED TO
BOTTOM OF ROOF
9'-10" MINIMUM OR FIXED CEILING
3" RISER
FIELD SUPPLIED DUCT
TURNING VANES
RECOMMENDED
12"
MINIMUM
4" MINIMUM FROM
TOP OF UNIT TO
DUCT BOTTOM
MIS-2989 B
FLOOR
OR FIXED CEILING
BOTTOM OF ROOF
SUSPENDED CEILING
MINIMUM
20"
7'-9 3/4"
UNIT HEIGHT
FIGURE 7B
3" Riser Application
