FIGURE 21
CRV Speed Change Terminal Access
REMOVE (5) SCREWS FROM
CRV DOOR TO ACCESS CRV
COMPONENTS
MIS-3023
CRV INTAKE BLOWER
NOTE: CRV EXHAUST
BLOWER IS BEHIND
INTAKE BLOWER
BLOWER SPEED
CONTROL LOCATION
BLOWER
SPEED
CONTROL
BLOWER REMOVED
FOR CLARITY
