Manual 2100-597G
Page 21 of 68
INTERIOR FLOOR
I-TEC UNIT
OUTSIDE WALL
FILL INSULATION
FILL INSULATION
OUTDOOR GRILLE
(SIZE VARIES)
INSIDE WALL
SLEEVE
MIS-2928 A
FIGURE 11B
Unit Mounting
