Bard I30A1DA - Figure 11 A Unit Mounting

Manual 2100-597G
Page 20 of 68
Pull Inner Frame
Out Until Flush
With Louver Mounting
Angle
Use (12) Field Supplied Concrete
or Wood Screws to Secure Outer
Sleeve to Structure.
Use care when inserting screws
to not damage gasketing material.
between inner and
IMPORTANT!
outer sleeve.
entire perimeter seam
seal between unit and sleeve.
IMPORTANT!
Doing so may compromise water
IMPORTANT!
Apply Caulk bead to
Apply liberal amount
of caulk to back of
flange before installing.
Screws to Attach
Unit Fan Shroud
Exhaust Sleeve to
Use (6) 3/4" Long
Self Tapping Screws
to Attach Inner Sleeve
Use (12) 3/4" Long
to Unit Back
to Outer Sleeve
to Attach Inner Sleeve
Self Tapping Screws
Use (6) 3/4" Long
Screws to Attach
Outer Sleeve.
Louver to
Use (4) 1-1/2" Long
Use (4) 1/2" Long
Screws to Attach
fra
me to Exhaust
Sleeve
A AND B
REF.
C
REF.
E
REF.
REF.
D
(4) 5/16" - 1/2" NON-TAPPING
(6) 5/16" - 3/4" NON-TAPPING
(18) 5/16" - 3/4" SELF TAPPING
(4) 1-1/2" LONG SCREWS
REF.
E
REF.
A
REF.
B
REF.
C
REF.
D
MIS-3014 B
NO CAULK
BEHIND Louver
FIGURE 11A
Unit Mounting
