Bard I30H1 - Figure 4 Req. Clearances & Rec. Access

Manual 2100-549G
Page 12 of 59
48" MIN.
31 3/8"
12" MIN. 12" MIN.
48"
MIN. FOR
FILTER ACCESS
24" MIN. 24" MIN.
12" MIN.
FOR RIGHT
SIDE
ACCESS
12" MIN.
FOR LEFT
SIDE
ACCESS
12" MIN. 12" MIN.
12" MIN. 12" MIN.
0" REQUIRED
12" RECOMENDED
0" REQUIRED
12" RECOMENDED
CLOSET CONSTRUCTION TOP VIEW
LEFT CORNER CONSTRUCTION TOP VIEW
RIGHT CORNER CONSTRUCTION TOP VIEW
FILTERS
RECOMMENDED SERVICE
ACCESS DIMENSIONS
WING WALL CONSTRUCTION TOP VIEW
MIS-3273
FIGURE 4
REQUIRED CLEARANCES & RECOMMENDED ACCESS
