FIGURE 21
CRV MOTOR SPEED/CFM CONFIGURATION
MED. HI
7961-7554
MOTOR SPEEDS
LO
MED. LO
HI
ORANGE
VENT OPTION INTAKE/EXHAUST SPEEDS
BROWN/WHITE
BLACK
BLUE
ORANGE
NOM. CFM
BLACK
BLUE
WIRE COLOR SPEED
RED
WIRE WITH WHITE TRACE.
300
375
450
525
LO
MED-LO
MED-HI
HI
RED
Move brown/white wire to corresponding motor
speed for required ventilation CFM. Factory
setting is Medium Lo (375 CFM).
TO CHANGE SPEEDS, MOVE BROWN
7961-755-2
MIS-3022 A
